| Jenis bayaran: | L/C,T/T,D/P |
| Pengangkutan: | Ocean,Land,Air,Express,others |
| Port: | shanghai,ningbo,huaian |
Teduh:
Jenama: Cepai
| Unit Jualan | : | Piece/Pieces |
| Jenis Pakej | : | Kotak |
The file is encrypted. Please fill in the following information to continue accessing it
Produk utama syarikat kami termasuk injap kawalan pneumatik 、 injap bola pneumatik 、 injap kawalan elektrik 、 Fluorine berjajar injap 、 precession vortex flowmeter 、 gear throttling.
| Type | straight ball valve |
| Nominal diameter | DN15-DN400mm |
| Nominal pressure | PN16,25;ANSI150 |
| Connection type | Flange type |
| Gland form | Platen type |
| Body material | WCB lined f46,CF8 lined F46,WCB lined PFA,CF8 lined PFA |
| Packing | V-type PTFE,flexible graphite |
Perhimpunan dalaman injap
| Spool form | Lined with plastic O-shaped ball core |
| Flow characteristice | fast open |
| Internal materials | WCB,CF8,CF8M with F46 or PFA |
Mekanisme Eksekutif
| Model | Electric actuator |
| Voltage | 220V,380V |
| Ambient temperature | -30~+70℃ |
| Control signal | 4-20mADC(4-20mA signal feedback can be provided according to customer requirements) |
Harta
| Leakage |
meets ANSI B16.104 Class Vl
|
